- Gross Power: 177 kW (237 hp)
- Gross Torque: 1,025 Nm (756 ft. – lb.)
- Operating Weight: 16,686 kg (36,787 lb.)
Simplified routing of the electrical and hydraulic systems improves reliability and eases service. Wiring and hoses are placed for protection against wear and damaging bends.
Continuously Variable Transmission
The easy-to-use CVT transmission automatically senses the load and delivers more torque and tractive effort as needed to maintain the desired speed.
New Steering Sensors
New steering sensors control articulation speed when nearing frame-to-frame contact, cushioning impact during full articulation and improving operator comfort.
Productive new two-speed 4000 Winch delivers internal gear-ratio changes and line speeds similar to the two-speed 6000 Winch.
Exceptionally low diesel exhaust fluid (DEF) consumption rate reduces the need for DEF compared to some other EPA Final Tier 4/EU Stage V systems.
Specs & Compare
Specs & Compare
|Select up to 4 models to compare specifications||
|Engine Manufacturer||John Deere|
|Engine Model||PowerTech PSS 6.8L|
|Displacement, ltr (Inches³)||6.8 (415)|
|Engine Output, kW (hp)||177 (237)|
|Engine Torque, Nm (lbf / ft)||1025 (756)|
|Transmission||Continuous Variable Transmission|
|Service Brake Type||Inboard Wet discs|
|Parking Brake Type||Wet multi-disc in Transmission|
|Overall Length, mm (inches)||7591 (298.9)|
|Height Over Cab, mm (inches)||3365 (132.5)|
|Overall Width, mm (inches)||3233 (127.3)|
|Wheelbase, mm (inches)||3680 (144.8)|
|Dozer Blade Height, mm (inches)||687.6 (27.1)|
|Ground Clearance, mm (inches)||555 (21.8)|
|Dozer Blade Width, mm (inches)||2192 (86.3)|
|Dozer Blade - Dig Depth, mm (inches)||359 (14.1)|
|Steering Articulation Angle, ± °||45|
|Fuel Tank, ltr (gallons (US))||342.2 (90.4)|
|Hydraulic Tank, ltr (gallons (US))||123.6 (32.6)|
|Alternator Output, Amp||150|
|Travel Speed, kph (mph)||24.74 (15.37)|
|Oscillation Point||Front axle|
|Oscillation Angle, ± °||15|
|Rated Line Pull, kN (lbf)||221 (49696)|
|Rated Line Speed, m/min (ft/min)||27.4 (90)|
|System Voltage, V||24|
|Operating Weight, kg (lbs)||16686 (36787)|
