John Deere Construction | Forwarders
- Net Power: 118 kW (160 hp) at 1,900 rpm
- Boom Reach: 9.8 m (32.2 ft.) / 8.5 m (27.9 ft.) / 10 m (32.8 ft.)
- Tractive Force: 150 kN (33,721 lbf) with 24.5 tires/ 110 kN (24,729 lbf.) with 22.5 tires
- Load Rating: 9000 kg (19,842 lb.)
- Optional Intelligent Boom Control eases boom operations, making them more precise and productive.
- Joysticks are configurable to user preference, so operators can run IBC using their preferred control patter.
Available with a 40-cm-shorter wheelbase, for better agility in thinnings, without compromising stability or load size.
Ideal for early to late thinning operations, the compact dimensions of the 910G maximizes productivity and power in the most demanding conditions.
Rotating, self-leveling cab turns 290 deg. for an all-around view of boom movements and the jobsite, for safe, efficient log loading.
Specs & Compare
|Specs & Compare|
|Select up to 4 models to compare specifications||
|Engine Manufacturer||John Deere|
|Engine Model||PowerTech Plus 4045|
|Displacement, ltr (Inches³)||4.5 (274.6)|
|Engine Output, kW (hp)||118 (158)|
|Engine Torque, Nm (lbf / ft)||650 (479.4)|
|Drive Configuration||8 x 8|
|Std tire size front||700 x 24.5|
|Std tire size rear||700 x 24.5|
|Base Carrier Length, mm (inches)||9055 (356.4)|
|Height Over Cab, mm (inches)||3685 (145.2)|
|Transport Height, mm (inches)||3685 (145.2)|
|Width, mm (inches)||2780 (109.2)|
|Wheelbase, mm (inches)||4800 (188.4)|
|Ground Clearance, mm (inches)||638 (25)|
|Width - Fixed Bunk, mm (inches)||2500 (98.4)|
|Horizontal Reach, m (ft/in)||9.6 (32 ft 2 in)|
|Load Length, mm (inches)||4090 (160.8)|
|Fuel Tank, ltr (gallons (US))||150 (39.6)|
|Hydraulic Tank, ltr (gallons (US))||150 (39.6)|
|Alternator Output, Amp||150|
|Lifting Moment - Standard Crane, kNm (lbf / ft)||76 (56)|
|Load Capacity, tonnes (tons (short))||10 (22046)|
|Travel Speed, kph (mph)||23 (14.3)|
|Tractive Force, kN (lbf)||110 (33721)|
|System Voltage, V||24|
|Pump Capacity, cm³ (Inches³)||120 (7.3)|
|Operating Weight, kg (lbs)||14950 (32959)|
